Main photo
Isuzu Tractor Head
4X2 ISUZU GIGA Tractor Head
Available Colors: Customization Logo: Customization
- Engine
- ISUZU engine
- Power
- 350 Hp (257 KW)
- Overall Dimension
- 5790 * 2500 * 3025 mm
- GVW / Kerb Weight
- 18,000 kg / 6,500 kg
- Drive Type
- 4×2, left hand drive
- Transmission
- 9 – speed forward, 1 reverse
- Emission
- Euro IV
- Wheelbase / Axles
- 3450 mm / 2
Specification below is the factory table for this model, reproduced without edits. 21 rows.
Introduction
4X2 ISUZU GIGA tractor head also called tractor Truck, tractor head truck, heavy haul tractor, mobile tractor unit, Traction head, tractor semi-truck, prime mover, etc.
ISUZU Tractor truck is a specialized towing engine that provides the motive power for hauling a towed or trailer-ed load.
Advantage
- ISUZU GIGA 6 wheel chassis, perfect performance
- ISUZU engine, super powerful, no overhaul within 500,000 km.
- Easy operation and easy maintenance.
- Euro V, Euro VI engines meet the environmental protection requirements of all countries.
- China largest Isuzu truck manufacturer, focusing on Isuzu truck manufacturing for 17 years.
- Top parts two-year warranty, after the warranty period, we only charge the cost price.
Tractor Head Specifications
4X2 ISUZU tractor head
| General | Brand | ISUZU |
|---|---|---|
| Overall Dimension | 5790 * 2500 * 3025 mm | |
| GVW / Kerb Weight | 18,000 kg / 6,500 kg | |
| Cab | Cab Capacity | 3 persons allowed |
| Air Conditioner | W/ air conditioner | |
| Engine | Fuel Type | Diesel |
| Engine Brand | ISUZU engine | |
| Power | 350 Hp (257 KW) | |
| Displacement | 9839 ml | |
| Emission Standard | Euro IV | |
| Chassis | Drive Type | 4×2, left hand drive |
| Transmission | 9 – speed forward, 1 reverse | |
| Wheelbase/No. of axle | 3450 mm / 2 | |
| Tyre Specification | 11.00-20 | |
| Tyre Number | 6 tyres and 1 spare tyre | |
| Max Speed | 90 km/h | |
| Fuel Tanker | 400 Liters made of aluminum alloy | |
| Fifth Wheel | 50# or 90# | |
| Paint | Metallic paint | |
| All other standard accessories: Tool kit, English manual | ||
| Optional | Medium cabin, high cabin. Burglar alarm & immobilizer, audible reverse beeper, reverse camera, central locking, GPS, VDR. JOST fifth wheel | |
Questions
Questions About The 4X2 ISUZU GIGA Tractor Head
What chassis is the 4X2 ISUZU GIGA Tractor Head built on?
It is built on the ISUZU chassis listed in the table. The full chassis detail including drive type, wheelbase, axle count and tyre specification is in the specification table on this page.
What is the capacity of this isuzu tractor head?
Other body sizes in this category are listed on the category page, and the factory can build to a customer drawing if none of them fit.
Can it be built to our own specification?
Yes, we can produce according to the customer's technical drawings and specifications.
How long before it is ready to ship?
Generally, it will take 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
How do we pay and what do we see before the balance?
T/T 30% as deposit, and 70% before delivery. We'll show you the photos or videos of the trucks before you pay the balance.
Is the truck tested before delivery?
Yes, we have 100% test before delivery. The whole vehicle is guaranteed for one year, and the core parts of some products are guaranteed for two years.
What support is available after it arrives?
Our overseas engineers will return visits on a regular basis, and provide professional technical training and truck manuals before delivery.
Related Models
Other Isuzu Tractor Head Builds
Same category, different capacity or chassis. Comparing the tables side by side is usually faster than asking.
3 Axle ISUZU GIGA Prime Mover
21 spec rowsView Details
6X4 ISUZU GIGA Tractor Truck for Sale
21 spec rowsView Details
Quote The 4X2 ISUZU GIGA Tractor Head
This build is listed as engine ISUZU engine with power 350 Hp (257 KW). Tell us the quantity and the destination port and you get a price, a photo of a comparable unit already built and a sailing estimate.
