Main photo
ISUZU Van Truck
ISUZU ELF 5 Ton Cargo Van Truck
Equipped Isuzu ELF cabin 98HP engine, Five-speed gearbox, double circuit oil brake, and direction assistance
- Chassis
- ISUZU
- Engine
- ISUZU
- Power
- 98 Hp (72 KW)
- Overall Dimension
- 5995X2300X3200 mm
- GVW / Kerb Weight
- 73,60 kg / 28,00 kg
- Drive Type
- 4X2, left hand drive
- Transmission
- 5 forward,1 reverse
- Emission
- Euro IV
Specification below is the factory table for this model, reproduced without edits. 23 rows.
Application
- ISUZU ELF 5 ton cargo van truck also called box vehicle, cargo truck, cargo van, box van, cube truck, lorry van, box truck is used to transport cargo with closed box. It is very normal and important transport truck.
- The material used for van truck body could be corrugated steel, color steel plate, fiberglass, aluminum or Stainless steel
- By adding cooling system and polyurethane insulation layer, van truck could be refrigeration truck and carry cargo or food that need be in low temperature.
- According to the requirements, it could be single door at rear or side, or double door.
ISUZU ELF 5 Ton Cargo Van Truck Advantage
- ISUZU ELF 100P chassis, perfect performance
- ISUZU engine, super powerful; reliable performance, no overhaul within 500,000 km.
- Accept customized
- Free logo and box paint
- Euro IV, Euro V, Euro VI engine
Specification
ISUZU ELF 5 ton cargo van truck
| General | Vehicle Brand | CHENGLI |
|---|---|---|
| Chassis Brand | ISUZU | |
| Overall Dimension | 5995X2300X3200 mm | |
| GVW / Kerb Weight | 73,60 kg / 28,00 kg | |
| Cab | Cab Capacity | 2 persons allowed |
| Air Conditioner | Air Conditioner Equipped | |
| Engine | Fuel Type | Diesel |
| Engine Brand | ISUZU | |
| Power | 98 Hp (72 KW) | |
| Displacement | 2771 ml | |
| Emission Standard | Euro IV | |
| Chassis | Drive Type | 4X2, left hand drive |
| Transmission | 5 forward,1 reverse | |
| Wheelbase/No. of axle | 3360 mm / 2 | |
| Tyre Specification | 6.50-16 | |
| Tyre Number | 6 tyres and 1 spare tyre | |
| Max Speed | 98 km/h | |
| Paint | Metallic paint | |
| Superstructure | Box Capacity | 2 tons |
| Box Material | Corrugated steel | |
| Dimension of Box | 4200 x 2050 x 2100 mm | |
| All standard accessories: tool kit, English Manual…… | ||
| Optional | ** Tank material could be color steel plate, fiberglass, aluminum… ** Cooling system and polyurethane insulation layer. | |
Truck Tools
- Free parts for 12 months.
- Supply of original parts.
- DHL serves 7 days worldwide.
Questions
Questions About The ISUZU ELF 5 Ton Cargo Van Truck
What chassis is the ISUZU ELF 5 Ton Cargo Van Truck built on?
It is built on ISUZU. The full chassis detail including drive type, wheelbase, axle count and tyre specification is in the specification table on this page.
What is the capacity of this isuzu van truck?
Other body sizes in this category are listed on the category page, and the factory can build to a customer drawing if none of them fit.
Can it be built to our own specification?
Yes, we can produce according to the customer's technical drawings and specifications.
How long before it is ready to ship?
Generally, it will take 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
How do we pay and what do we see before the balance?
T/T 30% as deposit, and 70% before delivery. We'll show you the photos or videos of the trucks before you pay the balance.
Is the truck tested before delivery?
Yes, we have 100% test before delivery. The whole vehicle is guaranteed for one year, and the core parts of some products are guaranteed for two years.
What support is available after it arrives?
Our overseas engineers will return visits on a regular basis, and provide professional technical training and truck manuals before delivery.
