Main photo
ISUZU Fecal Suction Truck
ISUZU Small 5000L Septic Tank Truck
ISUZU 5,000 liters cesspit emptier truck, ISUZU 4×2 Left Hand Drive chassis, MSB 5-shift manual gearbox, ISUZU 98 HP diesel engine, strong suction tanker
- Chassis
- ISUZU NKR
- Engine
- 4HK1
- Power
- 98HP (72 KW)
- Overall Dimension
- 5900X2000X2600 mm
- GVW / Kerb Weight
- 7,300 kg / 3,200 kg
- Drive Type
- 4X2, left or right hand drive
- Transmission
- 5-speed front, 1 reverse
- Emission
- Euro V
Specification below is the factory table for this model, reproduced without edits. 27 rows.
ISUZU Small 5000L Septic Tank Truck Description
- ISUZU septic tank truck also called cesspit emptier, toilet vacuum truck, toilet liquid tanker vehicle truck, toilet waste trucks, septic tank truck, Septic pump truck.
- Toilet vacuum truck is used to collect, transport and discharge liquid such as dirty water, sludge, septic, crude oil, and solid stuff such as small stones, bricks as well. Used to transport and unclog toilet feces.
Advantage
- 100% custom-made
- 3,000L to 20,000L available
- Short delivery time 7~30 days
- Easy operation & Easy maintenance
- 15 years spare parts & Technical support
- ISUZU ELF 100P chassis, perfect performance
- ISUZU technology engine option, super powerful, no overhaul within 500,000 km.
Specification
ISUZU 5000L septic tank truck
| General | Vehicle Brand | CHENGLI |
|---|---|---|
| Chassis Brand | ISUZU NKR | |
| Overall Dimension | 5900X2000X2600 mm | |
| GVW / Kerb Weight | 7,300 kg / 3,200 kg | |
| Cab | Cab Capacity | 3 persons allowed |
| Air Conditioner | Air conditioner is optional | |
| Engine | Fuel Type | Diesel |
| Engine Brand | 4HK1 | |
| Power | 98HP (72 KW) | |
| Displacement | 2999 ml | |
| Emission Standard | Euro V | |
| Chassis | Drive Type | 4X2, left or right hand drive |
| Transmission | 5-speed front, 1 reverse | |
| Wheelbase/No. of axle | 3360 mm / 2 | |
| Tyre Specification | 7.00-16 | |
| Tyre Number | 6 tyres and 1 spare tyre | |
| Max Speed | 95 km/h | |
| Paint | Metallic paint | |
| Superstructure | Tank Capacity | 5,000 Litres (1,300 gallons) |
| Tank Material | Carbon steel | |
| Vacuum Pump | Highly efficient, vacuum rate 93%, quick suction and discharge, suction lift 6m. | |
| Hose | High quality, wire strengthened hose | |
| All standard accessories: inlet, discharge, anti overflow valve | ||
| Optional | Tank material could be carbon steel, stainless steel Vacuum pump could be of imported brand | |
Working Parameter
ISUZU Small 5000L Septic Tank Truck Specification
| Extraction efficiency | Single full pumping≤5min | Sewage efficiency After a single row is ≤4min |
|---|---|---|
| Horizontal suction | 40-60 meters | Vertical suction ≤8m |
| Control method | Electric control + manual control | Operating position Cab + front of tank |
Vacuum Fecal Trucks Part, Tools and Instructions
- Free parts for 12 months.
- Supply of original parts.
- DHL serves 7 days worldwide.
Questions
Questions About The ISUZU Small 5000L Septic Tank Truck
What chassis is the ISUZU Small 5000L Septic Tank Truck built on?
It is built on ISUZU NKR. The full chassis detail including drive type, wheelbase, axle count and tyre specification is in the specification table on this page.
What is the capacity of this isuzu fecal suction truck?
Other body sizes in this category are listed on the category page, and the factory can build to a customer drawing if none of them fit.
Can it be built to our own specification?
Yes, we can produce according to the customer's technical drawings and specifications.
How long before it is ready to ship?
Generally, it will take 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
How do we pay and what do we see before the balance?
T/T 30% as deposit, and 70% before delivery. We'll show you the photos or videos of the trucks before you pay the balance.
Is the truck tested before delivery?
Yes, we have 100% test before delivery. The whole vehicle is guaranteed for one year, and the core parts of some products are guaranteed for two years.
What support is available after it arrives?
Our overseas engineers will return visits on a regular basis, and provide professional technical training and truck manuals before delivery.
