ISUZU Fire Water Tanker
ISUZU FVZ 4000 Gallon Fire Fighter Truck
Isuzu FVZ firefighter truck, Left Hand Drive model 6X4 chassis, 12 shift manual gearbox, 300 HP diesel engine
- Power
- 280HP
- Emission
- EURO 4,5,6
- Tanker Body
- 16,000L
- Tanker Shape
- Ellipse as standard
- Water Pump
- China Famous Brand 50m3/h
- Hand Lift the Pump
- 1 station
Specification below is the factory table for this model, reproduced without edits. 64 rows.
ISUZU FVZ 4000 Gallon Fire Fighter Truck Description
- ISUZU fire fighter truck also called fire fighting tanker, fire appliance, fire fighting engine, fire-extinguishing water truck, service truck, fire rescue truck, fire engine, fire tender, fire vehicle, fire fighting equipment, fire fighting foam tanker.
- This fire truck is designed primarily for fire fighting operations – to extinguish fire efficiently to prevent fire spread, reducing the loss caused by fire maximally.
- Fire fighting trucks types: Water fire truck, foam fire truck, Dry powder fire fighting truck, Emergency rescue fire truck, equipment fire truck and more.
- Application: Urban public fire brigade, Petroleum chemical industry, textile enterprise, cigarettes factory, ports, docks, forest and other departments.
- According to the fire agent, there are water tank fire fighting trucks, dry powder fire fighting trucks, water/foam fire fighting trucks.
Advantage
- 100% custom-made
- ISUZU FVZ heavy-duty Chassis, Durable & Performance.
- ISUZU engine & gearbox, super-powerful, no overhaul within 500,000 km.
- High-performance fire pump and fire cannon
- Water tank and Foam tank capacity can be optional.
- Tanker material: Carbon steel or Stainless steel
- With a complete set of fire fighting Accessories & Equipment, your can put in work immediately.
- Easy operation and easy maintenance.
- FREE training in our factory if you need it.
Specification
ISUZU FVZ 4000 Gallon Fire Fighter Truck Specification
| Manufacturer | CHENG LI | |
|---|---|---|
| Product Name | ISUZU FVZ 4000 gallon fire fighter truck | |
| Vehicle Brand Series | ISUZU FVZ | |
| Vehicle Model | CLW5126GSSD5 | |
| Production Time | 30 days | |
| Chassis parameters | Overall dimensions | mm 9900X2500X3000 |
| Gross weight | kg 25,000 | |
| Kerb weight | 10,800 | |
| Wheelbase | mm 5,100+1,350 | |
| Driving type | 6*4 | |
| Chassis model | ISUZU FVZ Heavy-duty | |
| Tire size | 12.00-20-16PR | |
| Number of Tires | 10+1 | |
| Passengers in cab | 3 | |
| Engine | Engine model | 6HK1-TCG40 |
| Type of fuel | Diesel | |
| Power | 280HP | |
| Max speed | Km/h 110 | |
| Emission standard | EURO 4,5,6 | |
| Water Tanker performance | Tanker Body | 16,000L |
| Body Material | Weather Resisting Steel | |
| Tanker Shape | Ellipse as standard | |
| Water Pump | China Famous Brand 50m3/h | |
| Optional Italy, Euro brand | ||
| Washing Width | ≥20 M | |
| Washing Speed | 5~20 km/h | |
| Rear Cannon Range | ≥50 M | |
| Spray Bar | Front, Side & Rear | |
| Hose & Hose-carrier | Factory standard | |
| Control Panel | English | |
| Walkway and Hand rail | Yes | |
| Painting | Two primers, and one final paint coating | |
| Color & LOGO | According to wish | |
| Factory standard | “U” shape Sub Frame, Hydraulic system, Ejector panel, Safety protection, Rotating Lamp, Working Lamp, Hand holds, Mudguards and rubber flaps… | |
| Documents | English operation manual, Spare parts list, and all necessary export docs. | |
| Optional equipment | 1, Stainless steel tank, Aluminum alloy tank 2, Wider platform and Fire Cannon 3, Electricity controlled separately sprinkler 4, Spreading salt water * Snow-melting agent | |
Fire Equipment Table
ISUZU FVZ 4000 Gallon Fire Fighter Truck Specification
| Serial number | name | specification Quantity unit Remarks |
|---|---|---|
| 1 | straw | 125×4 meters 2 root Threaded |
| 2 | Water filter | FLF125 1 Piece Threaded |
| 3 | Trap | FII80/65×3-1.6 1 Piece Internal button |
| 4 | Water trap | JII125/65×2-1.0 1 Piece Internal button |
| 5 | Hose | 13-65-20 6 plate Low pressure; |
| 6 | Hose | 13-80-20 6 plate Low pressure; |
| 7 | Reducing interface | KJ65/80 2 Piece Internal button |
| 8 | Water-retaining cloth | DT-SB 4 Piece Internal button |
| 9 | Hose hook | 4 Piece |
| 10 | Ground fire hydrant wrench | QT-DS1; length 400 1 Piece |
| 11 | Underground hydrant wrench | Long 860 1 Piece |
| 12 | Suction pipe wrench | FS100 2 Piece |
| 13 | DC switch water gun | QZG3.5/7.5; 65 1 support Low pressure; |
| 14 | DC Flowering Water Gun | QZK3.5/7.5; 65 1 support Low pressure; |
| 15 | Fire extinguisher | 3KG 1 With |
| 16 | Fire waist axe | Length 390; GF-285 1 Piece |
| 17 | Rubber hammer | 1 Piece |
| 18 | Rechargeable portable lighting | 1 Piece |
Optional Fire Equipment
ISUZU FVZ 4000 Gallon Fire Fighter Truck Specification
| Serial number | name | specification Quantity unit Remarks |
|---|---|---|
| 1 | Automatic charging device | 12V 1 set |
| 2 | Air backrest | 3 set |
| 3 | Air breathing apparatus | Number of members set |
| 4 | Hose bridge | rubber 2 vice |
| 5 | Telescopic ladder | 1 vice |
| 6 | Hand lift the pump | 1 station |
| 7 | Breaking tools | 1 set |
| 8 | Other fire equipment | |
Questions
Questions About The ISUZU FVZ 4000 Gallon Fire Fighter Truck
What chassis is the ISUZU FVZ 4000 Gallon Fire Fighter Truck built on?
It is built on the ISUZU chassis listed in the table. The full chassis detail including drive type, wheelbase, axle count and tyre specification is in the specification table on this page.
What is the capacity of this isuzu fire water tanker?
The factory table lists Tanker Body 16,000L. Other body sizes in this category are listed on the category page, and the factory can build to a customer drawing if none of them fit.
Can it be built to our own specification?
Yes, we can produce according to the customer's technical drawings and specifications.
How long before it is ready to ship?
Generally, it will take 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
How do we pay and what do we see before the balance?
T/T 30% as deposit, and 70% before delivery. We'll show you the photos or videos of the trucks before you pay the balance.
Is the truck tested before delivery?
Yes, we have 100% test before delivery. The whole vehicle is guaranteed for one year, and the core parts of some products are guaranteed for two years.
What support is available after it arrives?
Our overseas engineers will return visits on a regular basis, and provide professional technical training and truck manuals before delivery.
Related Models
Other ISUZU Fire Water Tanker Builds
Same category, different capacity or chassis. Comparing the tables side by side is usually faster than asking.
Quote The ISUZU FVZ 4000 Gallon Fire Fighter Truck
This build is listed as power 280HP with emission EURO 4,5,6. Tell us the quantity and the destination port and you get a price, a photo of a comparable unit already built and a sailing estimate.
