QINGLING ISUZU KV600/NQR 130HP Light Truck Chassis
QINGLING ISUZU KV600/NQR Light Truck Chassis adopts ISUZU 130HP diesel engine, Manual MSB 5-shift gearbox
- Payload:
- 6000kg
- Axle Loads:
- 3000/6000kg
- Capacity:
- 100L
- Product Origin
- China
- Body Size
- 6995x2150x2200 mm
- Shipping Port
- China
- Delivery Time
- Based on the mode of shipping chosen
Specification below is the factory table for this model, reproduced without edits. 33 rows.
QINGLING ISUZU KV600/NQR 130HP Light Truck Chassis Description
QINGLING ISUZU KV600/NQR 130HP Light Truck Chassis is from QINGLING, and the engine tech is from Japan which is named 600P in China. It can payload 5/6 tons. The transmission is Manual MSB-5, with 5 froward gears and 1 backward gear.
Advantage
- Cabin The new N-series Light Duty Truck’s new cabin model is adopted front headlight follow-up steering technology, new NKR cabin is more beautiful, comfortable, and safe. Qingling KV100 has a wider cab compared to 600P, and the front seats have been increased to 3.
- Power The new N-series Light Duty Truck is equipped with the new 4KH1 engine. 4K engine is characterized by an output power of 130 horsepower, electronic injection, intercooled supercharging technology, and a supercharger with a cooling device. The 4KH1CN engine has Supercharged cooling technology and an SCR/PDF Post processing system. The engine has strong power, low fuel consumption, reliable and durable.
- More environmentally friendly Qingling Trucks have achieved low pollution and low fuel consumption throughout the life cycle, and the performance of the whole vehicle is simultaneously improved, the noise is lower, the waggle is smaller, and the vehicle is quieter and more comfortable.
- More economical The fuel consumption of Qingling trucks is low, and the fuel cost is reduced by 10% – 15% compared with other vehicles with the same load capacity. It is high reliability, maintenance costs are low.
- Stronger oil adaptability Qingling is taking full account of users’ conditions of use, matching development, and improving the adaptability of oil products.
Specification
QINGLING ISUZU KV600/NQR 130HP Light Truck Chassis Specification
| Vehicle Model: | QINGLING ISUZU KV600/NQR Light Truck Chassis | |
|---|---|---|
| Chassis Dimensions and Parameters | Overall Dimension(L x W x H) | 6995×2150×2260mm |
| Wheelbase: | 3815mm | |
| Front/ Rear Wheel Distance: | 1685/1525mm | |
| Front/Rear Suspension | 1110/1525mm | |
| Weights and Capacities | Curb Weight: | 2600kg |
| Payload: | 6000kg | |
| GVW: | 8900kg | |
| Axle Loads: | 3000/6000kg | |
| Engine | Engine Model: | 4KH1CN5LS |
| Max output: | 96Kw | |
| Displacement: | 2999ml | |
| Horsepower: | 130Ps | |
| Exhaust Gas Treatment Technology： | DPF | |
| Transmission | Transmission: | MSB-5MT |
| Forward Gear: | 5 Speed Gear | |
| Backward Gear: | 1 Speed Gear | |
| Brake | Hydraulic Brake | |
| Front Drum Back Drum | ||
| Generator | 12V-60A | |
| Cab | Number of Seats: | 3 |
| Chassis | Drive Type: | 4×2 |
| Tires: | 7(Including Spare Tire) | |
| Tire Model: | 7.50R16 8PR | |
| Fuel Tank | Number: | 1 |
| Capacity: | 100L | |
| Configurations: | 1 | Power Steering System |
| 2 | Air Conditioning | |
| 3 | ABS | |
| 4 | Tubeless Tire | |
| 5 | Retro-reflective Marking | |
| 6 | Free Maintenance Battery | |
| 7 | Cab Tilting Mechanism | |
600P Advantage
- 19 years of design and export experience.
- 100% customized trucks.
- Quick delivery guarantee.
Factory Advantage:
Questions
Questions About The QINGLING ISUZU KV600/NQR 130HP Light Truck Chassis
What chassis is the QINGLING ISUZU KV600/NQR 130HP Light Truck Chassis built on?
It is built on the ISUZU chassis listed in the table. The full chassis detail including drive type, wheelbase, axle count and tyre specification is in the specification table on this page.
What is the capacity of this n-series light-duty trucks?
The factory table lists Payload: 6000kg. Other body sizes in this category are listed on the category page, and the factory can build to a customer drawing if none of them fit.
Can it be built to our own specification?
Yes, we can produce according to the customer's technical drawings and specifications.
How long before it is ready to ship?
Generally, it will take 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
How do we pay and what do we see before the balance?
T/T 30% as deposit, and 70% before delivery. We'll show you the photos or videos of the trucks before you pay the balance.
Is the truck tested before delivery?
Yes, we have 100% test before delivery. The whole vehicle is guaranteed for one year, and the core parts of some products are guaranteed for two years.
What support is available after it arrives?
Our overseas engineers will return visits on a regular basis, and provide professional technical training and truck manuals before delivery.
Related Models
Other N-Series Light-Duty Trucks Builds
Same category, different capacity or chassis. Comparing the tables side by side is usually faster than asking.
Quote The QINGLING ISUZU KV600/NQR 130HP Light Truck Chassis
This build is listed as payload: 6000kg with axle loads: 3000/6000kg. Tell us the quantity and the destination port and you get a price, a photo of a comparable unit already built and a sailing estimate.
