- ISUZU CXR 5000 Gallon Bobtail Fuel Truck for Sale
Main photo
Isuzu Fuel Truck
ISUZU CXR 5000 Gallon Bobtail Fuel Truck for Sale
Available Colors: Customization Logo: Customization
- Emission
- EURO III
- Front and Rear Axle Load
- 7T/18T
- Total Volume(m3)
- 20m3
- Tanker Body Material
- 5mm carbon steel
Specification below is the factory table for this model, reproduced without edits. 25 rows.
Introduction
ISUZU CXR 5000 gallon bobtail fuel truck (also called fuel oil bowser, diesel gasoline tanker bowser, fuel oil dispenser truck, petrol tanker truck, refuel bowser vehicle) is used to transport oil, diesel, gasoline, kerosene, etc.
ChengLi company Production fuel bowser can be divided into many compartments to transport different types of fuels, lubricant, crude oil, alcohol…
ISUZU fuel truck can be equipped with oil pump and refueling machine, flow meters all for easy operation.
Advantage
- ISUZU FVZ chassis, perfect performance
- ISUZU engine, super powerful, no overhaul within 500,000 km.
- Fuel Tanker capacity from 3 to 32 Cubic meters.
- Easy operation and easy maintenance.
- Euro V, Euro VI engines meet the environmental protection requirements of all countries.
- China largest Isuzu truck manufacturer, focusing on Isuzu truck manufacturing for 17 years.
- Top parts two-year warranty, after the warranty period, we only charge the cost price.
Specifications
ISUZU CXR 5000 gallon bobtail fuel truck General Technical Parameters
| Overall Dimension | 9900X2500X3300(mm) | Gross Vehicle Weight 25000(kg) |
|---|---|---|
| Curb Weight | 10850(kg) | Loading Weight 14950(kg) |
| Chassis Specification | ||
| Chassis Parameters | Brand | ISUZU |
| Cabin | Row and half, Left-Hand Driving | |
| Engine | Power 260HP | |
| Emission standard | EURO III | |
| Displacement | 7.79L | |
| Fuel type | Diesel | |
| Gearbox | FAST 9 Forward & 1 Reverse Gear | |
| Front and Rear Axle load | 7T/18T | |
| Wheel Base | 4350+1300(mm) | |
| Brake System | Pneumatic | |
| Steering Gear | Power Assistant | |
| Tire | 1000-20, 11 Pieces | |
| Maximum speed | 80(km/h) | |
| Tank Body | ||
| Shape | Monoblock Cylinder | |
| Total Volume(m3) | 20m3 | |
| Tanker Body Material | 5mm carbon steel | |
| Manhole Cover | ∮500mm,1 set with 1 breather valve | |
| Bottom Valve | 1 set | |
| Discharging Valve | 1 set ∮80mm discharging valve | |
| Painting | Complete Chassis sandblasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint | |
| Accessories | One standard toolbox | |
Fuel Tanker Truck Parts
- Free parts for 12 months.
- Supply of original parts.
- DHL serves 7 days worldwide.
Questions
Questions About The ISUZU CXR 5000 Gallon Bobtail Fuel Truck for Sale
What chassis is the ISUZU CXR 5000 Gallon Bobtail Fuel Truck for Sale built on?
It is built on the ISUZU chassis listed in the table. The full chassis detail including drive type, wheelbase, axle count and tyre specification is in the specification table on this page.
What is the capacity of this isuzu fuel truck?
The factory table lists Front and Rear Axle Load 7T/18T. Other body sizes in this category are listed on the category page, and the factory can build to a customer drawing if none of them fit.
Can it be built to our own specification?
Yes, we can produce according to the customer's technical drawings and specifications.
How long before it is ready to ship?
Generally, it will take 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
How do we pay and what do we see before the balance?
T/T 30% as deposit, and 70% before delivery. We'll show you the photos or videos of the trucks before you pay the balance.
Is the truck tested before delivery?
Yes, we have 100% test before delivery. The whole vehicle is guaranteed for one year, and the core parts of some products are guaranteed for two years.
What support is available after it arrives?
Our overseas engineers will return visits on a regular basis, and provide professional technical training and truck manuals before delivery.
Related Models
Other Isuzu Fuel Truck Builds
Same category, different capacity or chassis. Comparing the tables side by side is usually faster than asking.
Quote The ISUZU CXR 5000 Gallon Bobtail Fuel Truck for Sale
This build is listed as emission EURO III with front and rear axle load 7T/18T. Tell us the quantity and the destination port and you get a price, a photo of a comparable unit already built and a sailing estimate.
