Main photo
ISUZU Wrecker Tow Truck
ISUZU ELF 6 Ton Flatbed Tow Truck
ISUZU 6 tons flatbed wrecker tow truck, Left Hand Drive model 4×2 chassis, MLD 6-shift manual gearbox, ISUZU 190 HP diesel engine, long platform with hydraulic cylinder working
- Power
- 190HP
- Emission
- EURO 5,6
- Flatbed Payload Capacity
- 6,000 kg
- Winch Capacity
- 5,000 kg
- Washing Tank
- YES
Specification below is the factory table for this model, reproduced without edits. 36 rows.
ISUZU ELF 6 Ton Flatbed Tow Truck Description
- ISUZU flatbed tow truck also called tow wrecker truck, Flatbed recovery vehicle, Wrecker towing trucks used for safety salvage of vehicles subject to city road, suburb way, highway, airport and bridge road.
- It is suitable for medium and small-sized cargos, cars and other special vehicles, which are allowed within the technical parameters of this kind.
Advantage
- 100% custom-made
- 15 years spare parts & Technical support
- ISUZU engine & gearbox, super powerful, no overhaul within 500,000 km.
- 3 Ton to 50 Tons available
- Short delivery time 7~30 days
- Telescopic boom crane or Knuckle boom crane can be optional.
- Safety Devices are available, such as relief valves, balance valves, double-way hydraulic locks, motor emergency system etc.
- Easy operation & Easy maintenance
Specification
ISUZU ELF 6 Ton Flatbed Tow Truck Specification
| Manufacturer | CHENGLI COMPANY | |
|---|---|---|
| Product Name | ISUZU ELF 6 ton flatbed tow truck | |
| Vehicle Brand Series | ISUZU | |
| Vehicle Model | CLW5460GSST5 | |
| Production Time | 25 days | |
| Chassis parameters | Overall dimensions | mm 7500*2300*2350 |
| Gross weight | kg 13,800 | |
| Kerb weight | 4,500 | |
| Wheelbase | mm 4,175 | |
| Driving type | 4*2 | |
| Chassis model | ISUZU ELF middle-duty | |
| Tire size | 825R16 | |
| Number of Tires | 6+1 | |
| Passengers in cab | 3 | |
| Engine | Engine model | 4HK1-TC50 |
| Type of fuel | Diesel | |
| Power | 190HP | |
| Max speed | Km/h 110 | |
| Emission standard | EURO 5,6 | |
| Wrecker performance | Flatbed size | 5400*2300mm |
| Flatbed payload capacity | 6,000 kg | |
| Crane | Optional | |
| Under-lift | 5,000kg Towing capacity | |
| Max extended with 1.7 m | ||
| Winch no | 1 no | |
| Winch capacity | 5,000 kg | |
| Winch cable | 25 m length | |
| Washing tank | YES | |
| Operation | Hydraulic control | |
| Control Panel kit | Control lever kit on both side | |
| Auxiliary rescue equipment | Factoty | |
| Painting | Two primers, and one final paint coating | |
| Color & LOGO | According to wish | |
| Factory standard | “U” shape Sub Frame, 2 pcs Auxiliary wheels, Rear tail lights LED, both sides electronic lights, Hand washing water tank, 4 pcs bundling belt, Fork seat, Drag mechanism and so on. | |
| Documents | English operation manual, Spare parts list, and all necessary export docs. | |
| Optional equipment | 1, Wireless remote control 2, Aluminum alloy body 3, Italy imported multi-way valve 4, Optional different flatbed size. | |
ISUZU Flatbed Tow Truck Flatbed Recovery Vehicle Advantage
- Loading surface of the platform is formed by stamping die once.
- Endurance is strong and the shape is not deformed.
- Plate surface is smoother, the structure is more professional and the strength is higher.
- Hydraulic parts adopt internationally renowned brands, and the product quality is guaranteed.
- It integrates multiple functions such as lifting, carrying, dragging, pulling and so on.
- Hydraulic oil pipe is made of galvanized steel, which has good pressure resistance, strong heat dissipation performance, beautiful and durable.
Questions
Questions About The ISUZU ELF 6 Ton Flatbed Tow Truck
What chassis is the ISUZU ELF 6 Ton Flatbed Tow Truck built on?
It is built on the ISUZU chassis listed in the table. The full chassis detail including drive type, wheelbase, axle count and tyre specification is in the specification table on this page.
What is the capacity of this isuzu wrecker tow truck?
The factory table lists Flatbed Payload Capacity 6,000 kg. Other body sizes in this category are listed on the category page, and the factory can build to a customer drawing if none of them fit.
Can it be built to our own specification?
Yes, we can produce according to the customer's technical drawings and specifications.
How long before it is ready to ship?
Generally, it will take 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
How do we pay and what do we see before the balance?
T/T 30% as deposit, and 70% before delivery. We'll show you the photos or videos of the trucks before you pay the balance.
Is the truck tested before delivery?
Yes, we have 100% test before delivery. The whole vehicle is guaranteed for one year, and the core parts of some products are guaranteed for two years.
What support is available after it arrives?
Our overseas engineers will return visits on a regular basis, and provide professional technical training and truck manuals before delivery.
