ISUZU Hook Loader Truck
ISUZU GIGA 18m3 Roll Off Dumpster Truck for Sale
6X4 ISUZU GIGA chassis, FAST 12-shift manual gearbox, 350HP diesel engine, high strength hook loader system, with all kinds of garbage container optional
- Chassis
- ISUZU GIGA
- Engine
- ISUZU
- Power
- 350 HP (257 KW)
- Overall Dimension
- 9500X2400X3000 mm
- GVW / Kerb Weight
- 25,800kg / 10,200kg
- Drive Type
- 6×4, (left hand drive)
- Transmission
- 12 speed levers with 1 reverse
- Emission
- Euro 5
Specification below is the factory table for this model, reproduced without edits. 30 rows.
ISUZU GIGA 18m3 Roll Off Dumpster Truck Description
- Isuzu roll off dumpster truck is designed to collect and transport municipal solid waste, widely used in residence community, hospital, municipal environmental section, garbage collection and transportation station, etc.
- loading capacity can range from 1ton to 22tons, etc.
Advantage
- ISUZU GIGA chassis, perfect performance
- ISUZU engine, super powerful; reliable performance, no overhaul within 500,000 km.
- Rational design of hook boom and locking structure make the action of hook lift much more reliable;
- Safety devices: loading balance valve, double hydraulic lock valve, safety controlling valve, and locking structure of container by hydraulic;
- A rear support device is available.
- Hook loader garbage container body capacity from 1 to 22 Cubic meters.
- Rational design of hook and locking structure, and truck more reliable.
- Optional Electrical Control in the cabin, easy operation, and easy maintenance.
- Various types of refuse container lifters are available.
Specification
ISUZU GIGA 18m3 roll off dumpster truck for sale
| General | Vehicle Brand | CHENGLI |
|---|---|---|
| Chassis Brand | ISUZU GIGA | |
| Overall Dimension | 9500X2400X3000 mm | |
| GVW / Kerb Weight | 25,800kg / 10,200kg | |
| Cab | Cab Capacity | 3 persons allowed |
| Air Conditioner | Heating/cooling air conditioner | |
| Engine | Fuel Type | Diesel |
| Engine Brand | ISUZU | |
| Power | 350 HP (257 KW) | |
| Displacement | 9899 ml | |
| Emission Standard | Euro 5 | |
| Chassis | Drive Type | 6×4, (left hand drive) |
| Transmission | 12 speed levers with 1 reverse | |
| Wheelbase/No. of axle | 4350+1300 mm / 2 | |
| Tire Specification | 1100-20 | |
| Tire Number | 6 tires and 1 spare tire | |
| Max Speed | 90 km/h | |
| Paint | Metallic paint | |
| Superstructure | Lift Capacity | 18 Tons |
| Max dump angle | 51° | |
| Garbage bin volume | 4 cubic meters | |
| Hydraulic system pressure | 16 MPa | |
| Garbage bin material | Carbon steel | |
| Control | Hydraulic Manual | |
| Discharge method | Rear dumping | |
| All standard accessories: Warning lights, music alarm, basic tool kit, English manual | ||
| Optional | The backup alarm can be equipped. Other vacuum pumps can be equipped. Operation language can be English or Appointed language. | |
Working Parameter
ISUZU GIGA 18m3 Roll Off Dumpster Truck for Sale Specification
| Box time | Less than 15 seconds | Roller material Cast iron or forged steel |
|---|---|---|
| Unboxing time | Less than 15 seconds | Control method Electronic control + manual |
| Dump time | Less than 10 seconds | Operating position Cab + car side |
Garbage Collection Vehicle Tools and Instructions
- Free parts for 12 months.
- Supply of original parts.
- DHL serves 7 days worldwide.
Questions
Questions About The ISUZU GIGA 18m3 Roll Off Dumpster Truck for Sale
What chassis is the ISUZU GIGA 18m3 Roll Off Dumpster Truck for Sale built on?
It is built on ISUZU GIGA. The full chassis detail including drive type, wheelbase, axle count and tyre specification is in the specification table on this page.
What is the capacity of this isuzu hook loader truck?
Other body sizes in this category are listed on the category page, and the factory can build to a customer drawing if none of them fit.
Can it be built to our own specification?
Yes, we can produce according to the customer's technical drawings and specifications.
How long before it is ready to ship?
Generally, it will take 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
How do we pay and what do we see before the balance?
T/T 30% as deposit, and 70% before delivery. We'll show you the photos or videos of the trucks before you pay the balance.
Is the truck tested before delivery?
Yes, we have 100% test before delivery. The whole vehicle is guaranteed for one year, and the core parts of some products are guaranteed for two years.
What support is available after it arrives?
Our overseas engineers will return visits on a regular basis, and provide professional technical training and truck manuals before delivery.
Related Models
Other ISUZU Hook Loader Truck Builds
Same category, different capacity or chassis. Comparing the tables side by side is usually faster than asking.
ISUZU KV100 5m3 Roll Off Garbage Truck
23 spec rowsView Details
ISUZU 4m3 Roll Off Truck for Sale
30 spec rowsView Details
Quote The ISUZU GIGA 18m3 Roll Off Dumpster Truck for Sale
This build is listed as chassis ISUZU GIGA with engine ISUZU. Tell us the quantity and the destination port and you get a price, a photo of a comparable unit already built and a sailing estimate.
