ISUZU Fire Truck
ISUZU NMR 3500L Firetrucks Sale in Madagascar
Isuzu NMR firefighter truck, Left Hand Drive model 4×2 chassis, 6 shift manual gearbox, 190 HP diesel engine
- Chassis
- QL1100A8MAY
- Engine
- ISUZU
- Drive Type
- 4*2
- Transmission
- 6 speed, Manual
- Hand Lift the Pump
- 1 station
Specification below is the factory table for this model, reproduced without edits. 56 rows.
ISUZU NMR 3500L Firetrucks Description
- ISUZU 3500L firetrucks are also called fire fighting tankers, fire appliances, fire fighting engines, fire-extinguishing water trucks, service trucks, fire rescue trucks, fire engine, fire tender, fire vehicle, fire fighting equipment, fire fighting foam tanker.
- This fire truck is designed primarily for fire fighting operations – to extinguish fire efficiently to prevent fire spread, reducing the loss caused by fire maximally.
- Fire fighting trucks types: Water fire truck, foam fire truck, Dry powder fire fighting truck, Emergency rescue fire truck, equipment fire truck and more.
- Application: Urban public fire brigade, Petroleum chemical industry, textile enterprise, cigarettes factory, ports, docks, forest and other departments.
- According to the fire agent, there are water tank fire fighting trucks, dry powder fire fighting trucks, water/foam fire fighting trucks.
Advantage
- 100% custom-made
- ISUZU NQR heavy-duty Chassis, Durable & Performance.
- ISUZU engine & gearbox, super-powerful, no overhaul within 500,000 km.
- High-performance fire pump and fire cannon
- Water tank and Foam tank capacity can be optional.
- Tanker material: Carbon steel or Stainless steel
- With a complete set of fire fighting Accessories & Equipment, your can put in work immediately.
- Easy operation and easy maintenance.
- FREE training in our factory if you need it.
Specification
ISUZU NMR 3500L firetrucks sale in Madagascar
| Vehicle Parameters | ||
| General | Vehicle Model | CLW5100GXFSG30/Q |
|---|---|---|
| Vehicle Brand | CLW | |
| Chassis Brand | QL1100A8MAY | |
| Overall Dimension(mm) | 7390×2250×3000 | |
| GVW/Curb Weight(kg) | 9700/6225/3100 | |
| Chassis Parameters | ||
| Cab | Cab Seat | 2+3 |
| Air Conditioner | YES | |
| Engine | Fuel Type | diesel |
| Engie Model | 4HK1-TC51 | |
| Engine Brand | ISUZU | |
| Power(kw/hp) | 141/190 | |
| Displacement(cc) | 5193 | |
| Emmission Standard | Euro5 | |
| Chassis | Drive Type | 4*2 |
| Transmission | 6 speed, Manual | |
| Wheelbase(mm) | 4175 | |
| Tyre Specification | 235/75R17.5 | |
| Tyre No.(pcs) | 6+1 | |
| Max Speed(km/h) | 100 | |
| Paint | Red | |
| Fire Truck Water Tank Structure Parameters | ||
| Tank Volume | 3500L | Tank Material Carbon Steel |
| Tank Thickness | 4/3/3mm | Fire pump CB10/30 |
| Fire monitor | PS30 | Color and Optional |
| Standard configuration | Chassis,sub frame, van body,national standard equipment box, 25 units national standard fire-fighting equipment,fire pump(CB10/20, CB10/30,CB10/40,CB10/60 according to the capacity), fire gun(PS20 ,PS30,PS40,PS50 according to the capacity),fire power take off, sliding gate, row type lights, reel, common tools,rear climbing ladder,water tank. | |
| Selective configuration | foam type, dry powder type, stainless tank, other requirements. | |
Fire Equipment Table
ISUZU NMR 3500L Firetrucks Sale in Madagascar Specification
| Serial number | name | specification Quantity unit Remarks |
|---|---|---|
| 1 | straw | 125×4 meters 2 root Threaded |
| 2 | Water filter | FLF125 1 Piece Threaded |
| 3 | Trap | FII80/65×3-1.6 1 Piece Internal button |
| 4 | Water trap | JII125/65×2-1.0 1 Piece Internal button |
| 5 | Hose | 13-65-20 6 plate Low pressure; |
| 6 | Hose | 13-80-20 6 plate Low pressure; |
| 7 | Reducing interface | KJ65/80 2 Piece Internal button |
| 8 | Water-retaining cloth | DT-SB 4 Piece Internal button |
| 9 | Hose hook | 4 Piece |
| 10 | Ground fire hydrant wrench | QT-DS1; length 400 1 Piece |
| 11 | Underground hydrant wrench | Long 860 1 Piece |
| 12 | Suction pipe wrench | FS100 2 Piece |
| 13 | DC switch water gun | QZG3.5/7.5; 65 1 support Low pressure; |
| 14 | DC Flowering Water Gun | QZK3.5/7.5; 65 1 support Low pressure; |
| 15 | Fire extinguisher | 3KG 1 With |
| 16 | Fire waist axe | Length 390; GF-285 1 Piece |
| 17 | Rubber hammer | 1 Piece |
| 18 | Rechargeable portable lighting | 1 Piece |
Optional Fire Equipment
ISUZU NMR 3500L Firetrucks Sale in Madagascar Specification
| Serial number | name | specification Quantity unit Remarks |
|---|---|---|
| 1 | Automatic charging device | 12V 1 set |
| 2 | Air backrest | 3 set |
| 3 | Air breathing apparatus | Number of members set |
| 4 | Hose bridge | rubber 2 vice |
| 5 | Telescopic ladder | 1 vice |
| 6 | Hand lift the pump | 1 station |
| 7 | Breaking tools | 1 set |
| 8 | Other fire equipment | |
Questions
Questions About The ISUZU NMR 3500L Firetrucks Sale in Madagascar
What chassis is the ISUZU NMR 3500L Firetrucks Sale in Madagascar built on?
It is built on QL1100A8MAY. The full chassis detail including drive type, wheelbase, axle count and tyre specification is in the specification table on this page.
What is the capacity of this isuzu fire truck?
Other body sizes in this category are listed on the category page, and the factory can build to a customer drawing if none of them fit.
Can it be built to our own specification?
Yes, we can produce according to the customer's technical drawings and specifications.
How long before it is ready to ship?
Generally, it will take 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
How do we pay and what do we see before the balance?
T/T 30% as deposit, and 70% before delivery. We'll show you the photos or videos of the trucks before you pay the balance.
Is the truck tested before delivery?
Yes, we have 100% test before delivery. The whole vehicle is guaranteed for one year, and the core parts of some products are guaranteed for two years.
What support is available after it arrives?
Our overseas engineers will return visits on a regular basis, and provide professional technical training and truck manuals before delivery.
