ISUZU Dump Truck
ISUZU NPR 7 Cbm Forward Dump Truck Peru
ISUZU ELF 4×4 LHD chassis, MLD 6-shift manual gearbox, ISUZU 190HP diesel engine, high strength steel tipper body
- Max Loading Capacity (kg)
- 6400
- Load(kg)
- 3800
- Capacity (L)
- 175
- Product Origin
- China
- Body Size
- 7200X2500X3100 mm
- Shipping Port
- China
- Delivery Time
- Based on the mode of shipping chosen
Specification below is the factory table for this model, reproduced without edits. 30 rows.
ISUZU NPR 7 Cbm Forward Dump Truck Description
- ISUZU NPR 7 cbm forward dump truck also called dump truck, dump tipper, side-turn tipper, dump truck tipping, dumper, tip truck, tipper lorry.
- is a truck used for transporting loose material, such as sand, gravel, coal, dirt, etc.
- ISUZU dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front.
- Or hinged at side with hydraulic pistons to lift the side.
Advantage
- ISUZU ELF 700P light duty chassis, perfect performance
- 4HK1 engine, super powerful; reliable performance, no overhaul within 500,000 km.
- Pay loading from 2ton to 100 tons.
- Easy operation and easy maintenance.
- Virious types of tipper body are available.
- High strength box body
- Excellent Chinese brand hydraulic piston
- Strong, durable, perfect performance
Specification
ISUZU NPR 7 Cbm Forward Dump Truck Peru Specification
| Model | QL11009KARY 7CBM Isuzu forward dump truck Peru | |
|---|---|---|
| Dimensions | Length (mm) | 6500 |
| Width (mm) | 2300 | |
| Height (mm) | 2600 | |
| Wheel Base (mm) | 3815 | |
| Weight | Vehicle Curb Weight (kg) | 4600 |
| GVW (kg) | 11000 | |
| Max loading capacity (kg) | 6400 | |
| Performance | Max. Speed (km/h) | 110 |
| Approching angle(°) | 20 | |
| Departure angle(°) | 11 | |
| Core Equipments Specifications | ||
| Engine | Model | ISUZU 4HK1-TCG40,5.2 L,Euro IV emission standard |
| Rated Power (HP/KW) | 189HP/139KW | |
| Type | Diesel 4-cylinder in line, 4-stroke, water cooling, DENSO 1800 bar common rail injection+DOC | |
| Transmission | Model | MLD-6Q |
| Type | Manual | |
| Speed | 6F & 1R | |
| Front Axle | Type | ISUZU |
| Load(kg) | 3800 | |
| Rear Axle | Type | ISUZU |
| Load(kg) | 7200 | |
| Suspension | Type | Leaf spring |
| Dump box | Type | 4000X2000X800 MM,center lift |
| Standard Equipments Specifications | ||
| Driver’s Cab. | Type | ISUZU 700P, 3 SEATS |
| Air conditioner | Air condition | |
| Fuel Tank | Capacity (L) | 175 |
| Wheel&Tire | Type & Size | 8.25-20 |
| Color | According to client’s request | |
Questions
Questions About The ISUZU NPR 7 Cbm Forward Dump Truck Peru
What chassis is the ISUZU NPR 7 Cbm Forward Dump Truck Peru built on?
It is built on the ISUZU chassis listed in the table. The full chassis detail including drive type, wheelbase, axle count and tyre specification is in the specification table on this page.
What is the capacity of this isuzu dump truck?
The factory table lists Max Loading Capacity (kg) 6400. Other body sizes in this category are listed on the category page, and the factory can build to a customer drawing if none of them fit.
Can it be built to our own specification?
Yes, we can produce according to the customer's technical drawings and specifications.
How long before it is ready to ship?
Generally, it will take 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
How do we pay and what do we see before the balance?
T/T 30% as deposit, and 70% before delivery. We'll show you the photos or videos of the trucks before you pay the balance.
Is the truck tested before delivery?
Yes, we have 100% test before delivery. The whole vehicle is guaranteed for one year, and the core parts of some products are guaranteed for two years.
What support is available after it arrives?
Our overseas engineers will return visits on a regular basis, and provide professional technical training and truck manuals before delivery.
Related Models
Other ISUZU Dump Truck Builds
Same category, different capacity or chassis. Comparing the tables side by side is usually faster than asking.
Quote The ISUZU NPR 7 Cbm Forward Dump Truck Peru
This build is listed as max loading capacity (kg) 6400 with load(kg) 3800. Tell us the quantity and the destination port and you get a price, a photo of a comparable unit already built and a sailing estimate.
