- ISUZU NQR Light Duty 6 Cube Drop Side Tipper Truck for Sale
Main photo
ISUZU Dump Truck
ISUZU NQR Light Duty 6 Cube Drop Side Tipper Truck for Sale
ISUZU NQR 4×2 LHD chassis, MLD 6-shift manual gearbox, ISUZU 190HP diesel engine, high strength steel tipper body
- Delivery Capacity:
- 5193(ml)
- Axle Loads:
- Double Axles
- Dumper Capacity:
- 6.4m3
- Product Origin
- China
- Body Size
- 6600X2400X2600 mm
- Shipping Port
- China
- Delivery Time
- Based on the mode of shipping chosen
Specification below is the factory table for this model, reproduced without edits. 25 rows.
ISUZU NQR Light Duty 6 Cube Drop Side Tipper Truck Description
- Isuzu 6 cube drop side tipper truck also called dump truck, dump tipper, side-turn tipper, dump truck tipping, dumper, tip truck, tipper lorry, construction sand rock dump truck.
- is a truck used for transporting loose material, such as sand, gravel, coal, dirt, etc.
- ISUZU dump truck is equipped with an open-box bed, which is hinged at the rear and equipped with hydraulic pistons to lift the front.
- Or hinged at the side with hydraulic pistons to lift the side.
Advantage
- ISUZU NQR light-duty chassis, perfect performance
- 4HK1 engine, super powerful; reliable performance, no overhaul within 500,000 km.
- Pay loading from 2ton to 100 tons.
- Easy operation and easy maintenance.
- Virious types of tipper body are available.
- High-strength box body
- Excellent Chinese brand hydraulic piston
- The strong, durable, perfect performance
Specification
ISUZU NQR Light Duty 6 Cube Drop Side Tipper Truck for Sale Specification
| Chassis Parameters | Vehicle: | ISUZU NQR Light Duty 6 cube drop side tipper truck for sale |
|---|---|---|
| Overall Dimension(L x W x H) | 6605x2276x2450mm | |
| Curb Weight: | 5380Kg | |
| GVW: | 10000Kg | |
| Wheelbase: | 3815mm | |
| Drive Type: | 4×2 | |
| Engine | Engine Model: | 4HK1-TC40, Euro 4 |
| Engine Power: | 139(kW) | |
| Delivery Capacity: | 5193(ml) | |
| Horsepower: | 189PS | |
| Transmission | Transmission: | Isuzu MLD-6Q |
| Forward Gear: | 6 Speed Gear | |
| Backward Gear: | 1 Speed Gear | |
| Seats | Front Seat: | 3 |
| Chassis | Front Wheel Distance: | 1680mm |
| Rear Wheel Distance: | 1650mm | |
| Axle Loads: | Double Axles | |
| Rear Axle Ratio: | 4.1 | |
| Tires: | 7(including the spare tire) | |
| Tire Model: | 8.25R20 14PR | |
| Configuration | Power Steering, AC, Retro-reflective Marking, ABS, Free Maintenance Battery | |
| Top Parameter | Dumper Capacity: | 6.4m3 |
| Box Dimension(L x W x H) | 4000x2000x800mm | |
| Cylinder | Middle Lift, Single Hydraulic Jack | |
| The thickness of the Dump body | Bottom 4 side 3 |
Questions
Questions About The ISUZU NQR Light Duty 6 Cube Drop Side Tipper Truck for Sale
What chassis is the ISUZU NQR Light Duty 6 Cube Drop Side Tipper Truck for Sale built on?
It is built on the ISUZU chassis listed in the table. The full chassis detail including drive type, wheelbase, axle count and tyre specification is in the specification table on this page.
What is the capacity of this isuzu dump truck?
The factory table lists Delivery Capacity: 5193(ml). Other body sizes in this category are listed on the category page, and the factory can build to a customer drawing if none of them fit.
Can it be built to our own specification?
Yes, we can produce according to the customer's technical drawings and specifications.
How long before it is ready to ship?
Generally, it will take 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
How do we pay and what do we see before the balance?
T/T 30% as deposit, and 70% before delivery. We'll show you the photos or videos of the trucks before you pay the balance.
Is the truck tested before delivery?
Yes, we have 100% test before delivery. The whole vehicle is guaranteed for one year, and the core parts of some products are guaranteed for two years.
What support is available after it arrives?
Our overseas engineers will return visits on a regular basis, and provide professional technical training and truck manuals before delivery.
Related Models
Other ISUZU Dump Truck Builds
Same category, different capacity or chassis. Comparing the tables side by side is usually faster than asking.
Quote The ISUZU NQR Light Duty 6 Cube Drop Side Tipper Truck for Sale
This build is listed as delivery capacity: 5193(ml) with axle loads: Double Axles. Tell us the quantity and the destination port and you get a price, a photo of a comparable unit already built and a sailing estimate.
